Dual Head Pick & Place Machine HW-M8-102F
The HW-M8-102F is a high-precision, dual-head pick & place machine designed for efficient and accurate SMT (Surface Mount Technology) assembly. Engineered for small to medium-scale electronics manufacturing, this machine provides fast, automated component placement with superior precision.
With an advanced vision alignment system, automated feeder compatibility, and a user-friendly touchscreen interface, the HW-M8-102F ensures exceptional accuracy (±0.02mm) and placement speeds of up to 15,000 CPH. It is an ideal solution for industries that require cost-effective automation, such as consumer electronics, LED production, automotive electronics, and industrial applications.
Product Features
- Dual-Head Placement System – Increases efficiency by handling multiple components simultaneously.
- High-Speed Performance – Achieves up to 15,000 CPH (Components Per Hour), optimizing production cycles.
- Precision Vision Alignment – Ensures ±0.02mm placement accuracy for high-reliability PCB assembly.
- Versatile Component Handling – Supports a wide range of SMD components, from 0201 chips to large ICs (QFP, BGA, etc.).
- Multi-Feeder System – Compatible with multiple automatic feeders for continuous and efficient operation.
- User-Friendly Interface – Intelligent touchscreen control with real-time monitoring and customization options.
- Stable & Robust Construction – Built for 24/7 industrial operations with minimal maintenance.
Product Applications
- Consumer Electronics Production – Smart devices, IoT modules, industrial controllers.
- Automotive Electronics – PCBs for ECUs, sensors, infotainment, and LED lighting systems.
- LED PCB Assembly – LED display panels, lighting circuits, and automotive LED production.
- Medical Electronics – Diagnostic and monitoring equipment requiring high-precision PCB assembly.
- Industrial Automation – Used in control systems, robotics, and power electronics manufacturing.
